SPECIFICATIONS
- Engine : 230 V 0.6 HP single phase electric engine
- Pressure : 20 bar
- Flow rate : 19 l/min
- Crankshaft pump with Viton membrane and polypropylene manifold
- Pump rotation speed : 300/650 rpm
- Manual pressure regulator with pressure gauge and recycling & rinse valve
- Polypropylene detergent trap
- Multi-user option : possibility to have two operators working together
STANDARD EQUIPMENT
- 600 mm spray lance with adjustable handle
- 25 m hose
- 1.5 m suction hose with inlet filter
- 1.5 m return hose
- For all liquid products (except for products made from methylene chloride or cellulosic solvents)
- Usable products : see data sheet
Main features
- Place to fit the product can
- Hose holder
- Lance holder
MODELS| REFERENCE | FLOW RATE | PRESSURE | POWER | WEIGHT | DATA SHEET |
|---|---|---|---|---|---|
| l/min | bar | HP | kg | ||
| PE20ACCESS | 22 | 10 | 0.6 | 38 |
|
| PE20ACCESSED3 | 22 | 10 | 0.6 | 41 |
|
| PE20ED3 | 22 | 10 | 0.6 | 42 |
|
| PE20R | 22 | 10 | 0.6 | 39 |
|
