> >>High flow rate intensive three phase HP washers

High flow rate intensive three phase HP washers

SPECIFICATIONS
  • Crankshaft pump (radial), 3 ceramic pistons
  • Pump safety : Thermal safety valve
  • Regulator : separated from the manifold
  • Flector coupling : Increased elasticity of the motor-pump coupling
  • Three phase electric engine
  • Magneto-thermal circuit breaker
  • 5 m electric cable
  • Welded steel frame, epoxy paint
  • ABS hood
STANDARD EQUIPMENT
  • Hose : 10 m 3/8 double metal braided hose
  • Spray gun : with swivel link (on hose side)
  • Lance : 1050 mm double lance adjustable high & low pressure
  • Quick coupling : on the outlet of the pump
  • Pneumatic wheels : Ø 400 mm
Main features
  • Long-life pump
  • Anti water hammer regulator
  • Elastic coupling
  • Pneumatic wheels
  • Lance holders
  • Wheelbarrow arms
MODELS
REFERENCE FLOW RATE PRESSURE POWER PUMP WEIGHT FEATURES DATA SHEET DATA SHEET DATA SHEET DATA SHEET
l/min l/h bar HP rpm Brand Oil kg
IP21200 21 1260 200 12 1450 INTERPUMP 15W40 101
IP26150 26 1560 150 12 1450 INTERPUMP 15W40 101
IP30170 30 1800 170 12 1450 INTERPUMP 15W40 101
IP26150ST 26 1560 150 12 STOP TOTAL 1450 INTERPUMP 15W40 115 Stop total
